HD-TVI, 8 Channel Tribrid DVR - network recorder - EU-version
Works well also as an image splitter
Video signals - analogue HD / TVI / 960H
automatic NTSC/PAL recognition
Video input - 8 channels
Video output - BNC / VGA / HDMI
Video resolution - 1080p / 720p / QHD / 960H / Frame / Field / CIF
Recording control - manually / timer / motion / alarm / extern
Audio - 1 input / 1 output
Max. HDD capacity 2 x 6TB SATA HDD *
*HDDs are not part of this offer.
We would be happy to advise you on the selectin of suitable hard disc drives
The recording quality can be set to 4 levels
Ethernet net work connection via 10/100 Base-T
Protocols TCP/IP, PPPOE, DHCP and DDNS
supports external control and live view via Internet
Windows and MAC (Internet Explorer, Chrome and Safari)
mobile surveillance und control via smartphone with the app EagleEyes (for iOs & Android available)
Operating temperature from 10°C to 40°C
Humidity10 % bis 85 % relative humidity
Power supply (±10%) DC12V / 3A
Dimensions 345 x 68 x 225 mm
Weight 2,1 kg without HDD
Please see documents tab for further information like
Datasheet
Quickstart
Manual
Network Setup
